Smoke System 3.5V

• Rated for 18g
• 12v or 24v power ok
• Suitable for all aircraft
• Pump flow: 1.8 +/- GPM
• Spray rate: 0.8 +/- GPM
• Adjustable with incl valve
• Tank capacity: 3.5 gallons
• Total run time: 5+/- minutes
• Typical installation time: 1 day
• Ready for External Fill Kit option
• Engineered for continuous inverted flight
• Tank and pump easily removed and re-installed
• Strong monolithic tank construction (no seams)
• See successfully earned FAA Field approvals here
• Oil level quickly & easily determined (tank is transparent)


INCLUDES EVERYTHING NEEDED:

• Oil filter
• Electronics

• Check valve
• Suction hose
• Piston injector (1)
• Pressure hose (10')
• Stainless steel hose (3')
• 12v pump (& 24v to 12v converter)
  • Various pump models may ship based on availability


Note: Fasteners for attaching brackets to aircraft are not standardized and therefore not included.

DIMENSIONS:

• See image below

WEIGHT:

• Smoke System (full): 50 lbs
• Smoke System (empty): 20.5 lbs

Note: Weight increases if option(s) are added.
